參數 |
Specifications |
技術(shu)指標/Technique |
|
額定容量 |
Capacity |
100,200,500kg，1~5T |
|
輸出靈敏度 |
Rated output |
2.0±10%mV/V |
|
零點輸出 |
Zero balance |
±0.05mV/V |
|
非線性 |
Non-linearity |
0.1%F.S. |
|
滯后 |
Hysteresis |
0.1%F.S. |
|
重復性 |
Repeatability |
0.1%F.S. |
|
蠕變（30min） |
Creep(30min) |
0.1%F.S. |
|
溫(wen)度靈敏度漂(piao)移 |
Temp.effect on output |
0.05%F.S./10℃ |
|
零點溫(wen)度漂移 |
Temp.effect on zero |
0.05%F.S./10℃ |
|
輸入(ru)電阻 |
Input impedance |
800~1100Ω |
|
輸出(chu)電阻(zu) |
Output impedance |
800~1100Ω |
|
絕緣電阻 |
Insulation |
≥5000MΩ/100VDC |
|
激(ji)勵(li)電壓 |
Recommended excitation |
10V |
|
最大激(ji)勵電壓(ya) |
Maximum excitation |
15V |
|
溫(wen)度補償范圍(wei) |
Compensated temp range |
-10~60℃ |
|
工作溫度范圍 |
Operation temp range |
-20~80℃ |
|
安(an)全超載 |
Safe overload |
150%F.S. |
|
極限超(chao)載 |
Ultimate overload |
200%F.S. |
|
電(dian)纜(lan)線尺(chi)寸 |
Cable size |
Φ4×4000mm |
|
材料 |
Material |
Stainless Steel（不(bu)銹鋼） |
|
防護等級 |
IP Class |
IP66 |
